通風設備該如何減低噪音？

發布人：http://rdhw.com.cn   發布時間：2018-05-15 11:58:28

     通風設備是由電機帶動的，因為是機械設備，所以會存在一些噪音。很多人對通風設備的噪音很是反感，那在使用通風設備時如何降低噪音呢？
    Ventilator is driven by motor, because it is mechanical equipment, so there will be some noise. Many people are disgusted with the noise of ventilation equipment. How to reduce noise when using ventilation equipment?
    選擇合理的機型。在噪聲控制要求高的場合，應選用低噪聲通風設備。不同型號的通風設備，在同樣的風量、風壓下，機翼型葉片的離心通風設備噪聲小，前向板型葉片的離心噪聲大。
    Choose a reasonable model. When noise control requirements are high, low noise ventilation equipment should be selected. Under the same air volume and wind pressure, the centrifugal fans of the airfoil blades have little noise and the centrifugal noise of the forward blade is large under different air volume and wind pressure.
    通風設備的工作效率。同一型號的通風設備效率越高，噪聲越小。通風設備室的進、排氣通道采取消聲措施。
    The efficiency of the ventilation equipment. The higher the efficiency of the same type of ventilation, the smaller the noise. The intake and exhaust passages of the ventilation room adopt noise elimination measures.

    降低轉速可降低噪聲。在可能條件下適當降低通風設備的轉速，通風設備的旋轉噪聲與葉輪圓周速度10次方成比例，渦流噪聲與葉輪圓周速度5次方成比例。
    Reducing the speed can reduce the noise. Under the possible conditions, the rotational speed of the ventilator is properly reduced. The rotating noise of the ventilator is proportional to the 10 times of the circumferential velocity of the impeller, and the eddy noise is proportional to the 5 times of the circumference velocity of the impeller.
    通風設備進、出口的噪聲級是通風理、風壓增加而增大的。因此，設計通風系統時，應盡量減少系統的壓力損失。當通風系統的總風量和壓力損失較大時，可將其分為小系統。
    The noise level of inlet and outlet of ventilation equipment increases with ventilation and wind pressure increasing. Therefore, when designing the ventilation system, the pressure loss of the system should be minimized. When the total air volume and pressure loss of ventilation system are large, it can be divided into small systems.
    氣流在管道內的流速不宜過高，以免引起再生噪聲。確定管道內氣流流速應根據不同要求按有關規定選取。
    The velocity of the airflow in the pipeline should not be too high, so as not to cause regenerative noise. The flow velocity in the pipeline should be selected according to different requirements according to the relevant regulations.
    此外，還要注意通風設備與電動機的傳動方式。采用直聯傳動的通風設備噪聲較小，用聯軸器的次之，用沒有接縫的三角皮帶傳動的稍差。通風設備應配用低噪聲的電動機。
    In addition, we should also pay attention to the transmission mode of ventilation equipment and motor. The ventilation system with direct connection transmission is the least noise, followed by the coupling and slightly worse with the no joint triangle belt drive. A low noise motor should be used for the ventilation equipment.
