通風管道設計阻力平衡需要怎么處理？

發布人：http://rdhw.com.cn   發布時間：2018-06-21 11:58:14

一、在通風系統中的通風管道是相互連接的一個整體，必然得遵循各支路阻力平衡規律，當風管系統的結構 形式、管道尺寸一經確定，在一定的風機作用下，各段的風量是按阻力平衡規律自動分配的。在設計計算時未經阻力平衡計算，會導致系統實 際風量分配與設計不符。當然我們也可以通過調節風閥來分配風量，但這樣一來就又使非較不利環路的風壓多余。所以在設計計算時考慮各環 路的阻力平衡具有現實意義。

First, the ventilation pipe in the ventilation system is a whole which is connected to each other. It must follow the law of resistance balance of each branch. When the structure form and pipe size of the wind pipe system are determined, under the action of a certain fan, the air volume of each section is automatically divided according to the law of resistance balance. In the design calculation, the calculation of the actual air volume does not match the design without the calculation of the resistance balance. Of course, we can adjust the air volume by adjusting the air valve, but this will make the wind pressure of the non most unfavorable loop redundant. Therefore, it is of practical significance to consider the resistance balance of each loop when designing and calculating.

然而，不少設計人員在進行風道水力計算及阻力平衡過程中僅僅憑經驗估算或查圖手算，這樣費時費力還達不到理想效果。筆者所設計的計算 軟件以excel為工作平臺，用vba語言為開發工具，從而確保了程序的執行效率。

However, many designers only use experience estimation or map hand calculation in the process of wind tunnel hydraulic calculation and resistance balance, so that time consuming and hard work can not reach the ideal effect. The computing software designed by the author takes excel as the working platform and VBA language as the development tool, so as to ensure the efficiency of the program execution.

二、阻力自動平衡計算的基本步驟

Two, the basic steps of the automatic balance calculation of resistance

風道系統阻力平衡自動計算的執行過程基本延用常規設計的計算步驟，主要如下：

The implementation of automatic calculation of resistance balance in duct system basically extends the conventional design calculation steps, mainly as follows:

①將各節點間的邏輯關系、管段的相關參數依次輸入并保存，然后根據技術要求初步選定各管段的假定風速;

First, input the logical relationship between the nodes and the relevant parameters of the pipe in sequence, and then according to the technical requirements, the assumed wind speed of each section is preliminarily selected.

②根據假定風速自動計算管段當量水力直徑及阻力損失;

2. According to the assumed wind speed, the equivalent hydraulic diameter and resistance loss of the pipe section are automatically calculated.

③用節點逆尋法自動查找系統各環路的路徑及阻力損失，并確定系統較不利環路;

(3) find the path and resistance loss of each loop automatically by node inverse search method, and determine the most unfavorable loop of the system.

④對非不利環路進行自動阻力平衡。

(4) the automatic resistance balance is carried out on the non unfavorable loop.

⑤對計算結果進行校核。

Check the results of the calculation.

以上過程中只有工作量不大①、⑤需人工干預，而其他步驟全部由計算機自動完成。從而不但確保其計算速度及準確性，而且還可根據需要進 行適當?shù)氖止ふ{(diào)整。

In the above process, there is only a small amount of work and manual intervention. All other steps are automatically completed by the computer. It not only ensures the speed and accuracy of calculation, but also adjusts manually according to needs.
