通風系統中風管和風閥操作注意事項

發布人：http://rdhw.com.cn   發布時間：2018-08-28 16:02:10

在安裝算量中，有一個為暖通，其中通風系統是其中很重要的一環。以通風系統說一下操作的方法及注意事項。

One of the major installations is HVAC, and ventilation system is a very important part. Let's talk about the way of operation and matters needing attention in ventilation system.

通風系統在安裝算量中有兩種作法，一種是描圖方式，一種是轉化方式。這次針對性說一下轉化方式的應用。

Firstly, there are two ways to calculate the installation amount of ventilation system, one is the drawing method, the other is the transformation method. This is about the application of transformation.

通風考慮的主要有風口、風管、風閥、風設備及一些附件。

The main consideration of ventilation is tuyere, wind pipe, air valve, wind equipment and some accessories.

本次主要強調通風系統中風管和風閥操作注意事項：

This article mainly emphasizes the matters needing attention in the operation of the ventilation system and the wind valve.

一、風管的識別

1. Identification of duct

對于風管的轉化之前，有一個內容必須要先明確，那就是關于風管的標高。用高度調整命令查看時，有時顯示出來的結果不一樣。那是因?yàn)椋芫€和管道的標高就是線或管的中心標高，平時再說管道多高時，就是把管道看成一根線。而如果做風管，那在表示標高時，方法就有些不同。要說風管管底標高，還是中心標高，還是頂標高。所以在風管之前，要看清圖紙上的風管將來是上平齊，還是下平齊，還是中心齊，那相對應的調整管底標高，中心標高和頂標高。（此外，在做風管轉化時，也要針對性的要使用對應的一種）。

Before the transformation of the duct, one thing must be made clear, that is, the elevation of the duct. When viewed with height adjustment commands, sometimes the results are different. That's because the elevation of pipelines and pipes is the central elevation of the line or pipe, usually say how high the pipe, is to regard the pipe as a line. If the duct is made, the method is somewhat different when it indicates the elevation. The height of the bottom of the wind pipe is either the center elevation or the top elevation. So before the duct, it is necessary to see clearly whether the duct on the drawing will be uniform in the future, or even in the bottom, or even in the center, which corresponds to the adjustment of the pipe bottom elevation, center elevation and top elevation. (in addition, when the duct is transformed, the corresponding one should be used accordingly.

那現在要做好風管轉化，這一步要輸入好以下方面：一是風管的材質，二是風管的壁厚，三是風管的接口型式，四是風管的保溫厚度。這些參數較好看一下說明，如果沒有的話參考05N4-3的相關規定。

Now we must do a good job of air duct conversion, this step to input the following aspects: first, the material of the air duct, second, the wall thickness of the air duct, third, the interface type of the air duct, fourth, the insulation thickness of the air duct. These parameters should be taken into account. If not, refer to the relevant regulations of 05N4-3.

二、風閥的繪制及注意事項

Two. Drawing and noticing of air valve

關于風閥可以用轉化，也可以直接繪制，方法可以參考轉化設備。這里說一下風閥中比較特殊的內容。在管道里面，閥門是不扣減管道長度的，但在風管里面，風閥是要扣減掉風管的長度的，對于不同的風閥類型，有不同的扣減方法。如下圖所示,有的是風管寬度不論什么值，風閥只扣一個固定值；有的是風管寬度論什么值，風閥長度扣固定加上風管的高度（或半徑）；還有一種情況，風管的寬度與風閥的長度有一個對應關系。我們可以根據具體的說明來選擇不同的風閥類別。

The wind valve can be transformed or directly drawn. The method can refer to the transformation equipment. Here is a special description of the wind valve. In the pipeline profession, the valve does not deduct the length of the pipe, but in the duct, the air valve is to deduct the length of the duct, for different types of air valve, there are different deduction methods. As shown in the following figure, some of the air duct widths, no matter what the value of the wind valve buckle only a fixed value; some of the air duct widths, wind valve length buckle fixed plus the height of the air duct (or radius); and another case, the width of the air duct and the length of the air valve has a corresponding relationship. We can choose different types of wind valves according to specific instructions.
