鍍鋅風管的優勢你知道多少呢？

發布人：http://rdhw.com.cn   發布時間：2018-11-13 11:28:29

鍍鋅風管的優勢

Advantages of galvanized air ducts

1.機械加工成型的制作能夠使鍍鋅板不易受到損壞，使鍍鋅層不輕易被損傷，這樣很好的增加了風管的使用時間。

1. The manufacture of mechanical forming can make galvanized sheet not easy to be damaged and galvanized layer not easy to be damaged, which greatly increases the service time of air duct.

2.規格一樣，尺寸標準，保證了風管內部平整，光滑，便于清潔 ，可以使物料輸送流暢。

2. The same specifications, size standards, to ensure that the inside of the duct is smooth, smooth, easy to clean, can make material delivery smooth.

3.自成型法蘭的管道它使用的材料統一，沒有使用角鋼法蘭，這樣可以大大減輕了風管本身的重量，這樣建筑物的承荷能力將會大大減小，這樣就從根本上減少了建筑物的造價。

3. The pipes with self-forming flange use uniform materials and do not use angle steel flange, which can greatly reduce the weight of the air duct itself, so that the bearing capacity of the building will be greatly reduced, thus fundamentally reducing the cost of the building.

4.加強了風管自身的美觀，主要有，構造上的精巧，外觀線條上的柔和，使用性能上的。

4. Strengthen the beauty of the air duct itself, mainly in its delicate structure, soft appearance and excellent performance.

5.因為是標準化的生產流程，所以風管的氣密性很好，嚴謹?shù)牧魉€制作，使每個風管的部件及接頭和零配件都有良好的密封性。

5. Because it is a standardized production process, the air tightness of the air duct is very good, rigorous production line, so that each air duct parts and joints and spare parts have good sealing.

6.標準化加工產生的加強筋、壓筋，增強了管道自身的強度，減少了材料的厚度，大大降低了成本。螺旋風管的咬口潛縫厚度是管體的4倍，使管道的剛性非常大，擁有較優的承壓能力。

6. The reinforcing bars and compressing bars produced by standardized processing enhance the strength of the pipeline itself, reduce the thickness of the material and greatly reduce the cost. The thickness of the submerged slot of the spiral duct is four times that of the tube body, which makes the pipeline very rigid and has the best pressure bearing capacity.

7.采用的焊接方式具有特色，低溫焊接的方式，從而可以保證產品的鍍層不輕易被損壞，這樣做出的部件及牢固又美觀且密封性較好，焊后不用做處理。

7. The welding method adopted has its own characteristics. The low temperature welding method can ensure that the coating of the product is not easily damaged. The parts made in this way are firm, beautiful and sealable, and need not be treated after welding.

安裝鍍鋅風管的時候應該注意的事情

Something to note when installing galvanized duct

1.在安裝前需要檢查產品是否合格，如果合格就進行部件的組裝，較后再進行風管的清潔與高空的安裝。

1. Before installation, we need to check whether the product is qualified. If it is qualified, we need to assemble the components. Finally, we need to clean the air duct and install it at high altitude.

2.產品在安裝時，應控制每個風管之間的間距小于4M，尤其是單個直管之間必須要有不低于2個及以上的固定位定住。

2. When installing the product, the distance between each air duct should be controlled to be less than 4M. Especially, there must be no less than two or more fixed positions between single straight duct.

3.在安裝產品過程中，需要使用的調隔離的振支和吊桿拉伸，應當根據設計的要求和實際的情況進行適當?shù)男薷摹?/span>

3. In the process of installing products, the vibration support and suspender tension which need to be adjusted and isolated should be modified appropriately according to the design requirements and actual conditions.

4.鍍鋅風管吊架的螺孔可使用機械加工進行安裝。同時吊桿應保持平直，螺紋完整和光潔。安裝之后應檢查各副支、吊架之間的受力是否均勻。

4. the screw hole of the galvanized air duct hanger can be installed by mechanical processing. Meanwhile, the hanger should be straight and threaded. After installation, check whether the forces between the sub supports and hangers are even.

5.在安裝鍍鋅風管的彎管時，一定要添加導流片，以確保風管有正常的輸送風力。如果是矩形彎管的話，可以采用三通或者四通進行連接，安裝的方式大多數采用分叉式或分隔式進行安裝。

5. When installing the elbow of galvanized duct, the guide vane must be added to ensure that the duct has normal conveying wind power. If rectangular elbow is used, three-way or four-way connection can be used. Most of the installation methods are bifurcated or separated.

6.在安裝過程中要特別注意風管和法蘭之間翻邊的情況，應盡量保證翻邊的平整，保持連接寬度的一致。

6. In the process of installation, special attention should be paid to the flanging between the air duct and the flange, and the flanging should be as smooth as possible to maintain the consistency of the connection width.

較后有一個重要的環節，就是要注意風管吊桿的施工，要做好高度統一的調節工作，只有高度一致的時候，每個吊桿才能夠充分發揮各自的作用。

Finally, there is an important link, that is to pay attention to the construction of air duct hangers, to do a highly unified adjustment work, only when the height of consistency, each hanger can give full play to their respective roles.
