玻璃鋼風管有什么優勢？

發布人：http://rdhw.com.cn   發布時間：2019-02-07 13:29:39

玻璃鋼防腐風管是以無機復合材料為膠結料，以玻璃布為增強材料，配以增韌劑、增強劑和抗水劑、膠凝劑和增白劑等，通過嚴格的調制程序、加工工藝和養護過程，固化形成整體綱絡骨架結構，它具有輕質高強、耐腐蝕抗老化、、減振消音、保溫隔熱、耐熱不燃、不變形、不裂紋、不吸潮、不返鹵、體積穩定性好、使用壽命長、成本低等優點，從而解決了有機玻璃鋼風管易燃燒、鐵皮風管易腐蝕、使用壽命短的難題。
　　FRP anti-corrosive duct is a kind of integral framework structure, which is made of inorganic composite material as binder, glass cloth as reinforcing material, toughening agent, reinforcing agent, water-resisting agent, gelling agent and whitening agent. Through strict modulation procedure, processing technology and maintenance process, FRP anti-corrosive duct has the characteristics of light weight, high strength, corrosion and aging resistance, non-toxicity, vibration reduction, sound insulation and heat resistance. Non-flammable, non-deforming, non-cracking, non-moisture absorption, non-halogen return, good volume stability, long service life, low cost and other advantages, thus solving the problem of PMFRP ducts easy to burn, iron ducts easy to corrode, short service life.
　　玻璃鋼風管產品優勢： 管用50年
　　Advantages of FRP Wind Pipe Products: 50 Years of Pipe Use
　　耐熱性、抗凍性能好：可–50℃~130℃的范圍內使用。
　　Good heat resistance and frost resistance: It can be used in the range of 50 130 C.
　　詳細參數說明：
　　Detailed parameter description:
　　直徑大：直徑范圍50–4000mm 工作壓力0-5.0MPa
　　Large Diameter: 50-4000mm Diameter Working Pressure 0-5.0MPa
　　強度高：環向抗拉強度：320Mpa，軸向拉伸強度220Mpa（強度可按需設計）
　　High strength: circumferential tensile strength: 320 Mpa, axial tensile strength 220 Mpa (strength can be designed on demand)
　　玻璃鋼風管剛度高：樹脂石英砂夾層結構。1250、2500、3750、5000、10000N/M及以上。
　　Fiberglass reinforced plastic duct has high stiffness: resin quartz sand sandwich structure. 1250, 2500, 3750, 5000, 10000N/M and above.
　　防滲漏：富樹脂內襯層和襖致密度結構層，里外防滲漏。
　　Leakage prevention: resin-rich lining and dense structure layer, inside and outside leakage prevention.
　　重量輕：一般只有同口徑鋼管的1/4，水泥管的1/10，安裝費用低。
　　Light weight: generally only 1/4 of the same diameter steel pipe, 1/10 of the cement pipe, low installation costs.

　　耐腐蝕：耐腐蝕性能特別優異，可輸送腐蝕介質和任何污水。
　　Corrosion resistance: Excellent corrosion resistance, can transport corrosive media and any sewage.
　　電絕緣：擊穿電壓12–16KV/mm。
　　Electrical insulation: breakdown voltage 12-16KV/mm.
　　內壁光滑：水力摩擦系數小且長期穩定，具有可觀的效益。
　　Smooth inner wall: small hydraulic friction coefficient and long-term stability, with considerable energy-saving benefits.
　　抗凍性能好：水結冰后不凍裂。
　　Good frost resistance: water does not freeze crack after freezing.
　　保溫性能好：導熱系數僅為鋼管的1/233。
　　Good thermal insulation performance: thermal conductivity is only 1/233 of steel pipe.
　　玻璃鋼風管使用壽命長：按50年設計。將使用壽命納入國內外標準的產品。
　　Long service life of FRP air duct: designed according to 50 years. Products that incorporate service life into domestic and international standards.
　　玻璃鋼風管輸水性能好：采用乙烯基樹脂，水質優良、無任何異味，且長期使用不結垢，避光條件下不產生微生物。
　　Fiberglass reinforced plastic duct has good water transporting performance: Vinyl resin is used, water quality is excellent, no odor, and no scaling, no microorganisms are produced in the long-term use of the duct under the condition of avoiding light.
