裝置通風管道?如何合理布局呢？

發布人：http://rdhw.com.cn   發布時間：2020-02-19 19:49:07

隨著市場的快速發展，對風管的需求量越來越大。在各行各業，它已經成為人們生活中不可缺少的一部分。通風管道系統布置平整美觀，簡單緊湊，便于安裝、操作和維護等。通風管道安裝系統布局的一般步驟是什么?我應該注意什么?
　　With the rapid development of the market, the demand for air ducts is increasing. In all walks of life, it has become an indispensable part of people's life. The layout of ventilation duct system is flat and beautiful, simple and compact, easy to install, operate and maintain. What are the general steps in the layout of the ventilation duct installation system? What should I pay attention to?
　　通風管道處理的系統布置應遵循以下幾點:
　　The system layout of ventilation pipe treatment shall follow the following points:
　　為了便于管網的管理和運行調節，管網系統不宜過大。當同一系統中有多個支管時，應對這些支管進行分級控制，同一系統的吸力點不宜過多，并注意各支管的壓力平衡。常用的管網布置形式有干管布置、單管布置和環管布置。
　　In order to facilitate the management and operation of the pipe network, the pipe network system should not be too large. When there are more than one branch pipes in the same system, the branch pipes shall be controlled in different levels. The suction points of the same system shall not be too many, and the pressure balance of each branch pipe shall be paid attention to. The common pipe network layout forms are main pipe layout, single pipe layout and ring pipe layout.
　　二是布局原則
　　Second, layout principle
　　1. 通風管道敷設系統原理
　　1. Principle of ventilation pipe laying system
　　管道鋪設清晰、深色，一般采用平直。因為安裝簡單,易于維護,當使用純安裝可以不考慮黑暗的安裝,管道盡可能為一行,盡可能沿墻或列平行鋪設,如果管徑或絕緣應安排在墻上。兩根管道平行敷設時，間距一般不小于100 ~ 200mm。
　　The pipeline laying shall be clear and dark, and generally straight. Because the installation is simple and easy to maintain, when using the pure installation, the dark installation may not be considered. The pipeline shall be laid in one line as far as possible and parallel along the wall or column as far as possible. If the pipe diameter or insulation is arranged on the wall. When two pipes are laid in parallel, the spacing is generally not less than 100 ~ 200mm.

　　2. 通風管道處理系統的連接原理
　　2. Connection principle of ventilation pipe processing system
　　以焊接為主要連接方式的管道應設置足夠數量的法蘭連接，螺紋連接管道應設置足夠的活動接頭，便于安裝、拆卸和檢修。
　　Enough flange connection shall be set for pipes with welding as the main connection mode, and enough movable joints shall be set for threaded pipes to facilitate installation, disassembly and maintenance.
　　3.通風管道安裝處理系統的支撐原理不能由管道和閥門直接支撐在設備上。支架或吊架應單獨設置。
　　3. The supporting principle of the installation and treatment system of the ventilation pipe cannot be directly supported on the equipment by the pipe and valve. Supports or hangers shall be set separately.
　　4. 不同含塵氣體具有不同的性質，因此凈化的分段處理應有所不同。
　　4. Different dust-containing gases have different properties, so the treatment of purification in sections should be different.
　　當污染源數量較大時，可以集中在一個凈化系統中，也可以分為多個凈化系統。然而，當污染物與氣體混合后，可能會引起燃燒、爆炸危險、不同的溫度和濕度、冷凝、粉塵或氣體的性質在管道中混合后，可能會影響回收或凈化效率。
　　When the number of pollution sources is large, they can be concentrated in one purification system or divided into multiple purification systems. However, when the pollutants are mixed with the gas, it may cause combustion, explosion hazard, different temperature and humidity, condensation, dust or gas properties mixed in the pipeline, which may affect the recovery or purification efficiency.
　　5、通風管道處理系統布置要保證整個系統的泄漏量很小，要保證吸入口有足夠的風量。
　　5. The layout of the ventilation pipeline treatment system shall ensure that the leakage of the whole system is very small and that the suction port has enough air volume.
　　6、通風管道處理系統布置，減少阻力。
　　6. Arrangement of ventilation pipe treatment system to reduce resistance.
　　以上就是山東通風管道對通風管道如何合理布局的詳細介紹，想要了解更多請點擊官網http://rdhw.com.cn
　　The above is a detailed introduction of how to arrange the ventilation pipes in Shandong Province. For more information, please click http://rdhw.com.cn
