螺旋風管常見的兩種安裝方法

發布人：http://rdhw.com.cn   發布時間：2022-06-09 19:38:21

螺旋風管常見的兩種安裝方法

Two common installation methods of spiral air duct

風管很多人可能聽過到時沒見到過，其實它廣泛的應用在我們的身邊，為我們的生活提供者相應的便利，今天小編就帶大家看看螺旋風管常見的兩種安裝方法。

Many people may have heard of the air duct but haven't seen it. In fact, it is widely used around us and provides corresponding convenience for our life. Today, Xiaobian will show you two common installation methods of spiral air duct.

1. 支架、衣架的制造與安裝

1. manufacturing and installation of supports and hangers

2.


根據規范要求，不同規格的螺旋風管應采用不同尺寸的支架和吊架。吊架的長度應根據鍍鋅風管的尺寸和安裝高度以及地梁或鋼架的高度進行剪裁加工。衣架的掛碼應采用角鋼加工，衣架端部的螺紋應符合調整鍍鋅螺旋風管高度的要求。衣架頂部應焊接固定角鋼碼，衣架應刷兩遍防銹漆和面漆。吊架完成后，可按照鍍鋅螺旋風管的布置方向進行安裝，其間距符合設計規范要求。

According to the specification requirements, spiral air ducts of different specifications shall adopt supports and hangers of different sizes. The length of the hanger shall be cut according to the size and installation height of the galvanized air duct and the height of the ground beam or steel frame. The hanger of the hanger shall be processed with angle steel, and the thread at the end of the hanger shall meet the requirements for adjusting the height of the galvanized spiral air duct. The top of the hanger shall be welded with fixed angle steel code, and the hanger shall be painted with two coats of antirust paint and finish paint. After the hanger is completed, it can be installed according to the layout direction of galvanized spiral air duct, and its spacing shall meet the requirements of design specifications.

2、鍍鋅螺旋風管的吊裝

2. Hoisting of galvanized spiral air duct

根據設計圖紙和規范的要求，應安裝鍍鋅螺旋風管。安裝螺旋風管前，應將裝配部位清洗干凈。之后，根據圖中螺旋風管的分布情況，將組裝好的鍍鋅螺旋風管按照鍍鋅螺旋風管的數量進行排列組合，并檢查鍍鋅螺旋風管的尺寸。軸位符合圖紙后，即可進行吊裝。

Galvanized spiral air duct shall be installed according to the requirements of design drawings and national specifications. Before installing the spiral air duct, clean the assembly part. Then, according to the distribution of spiral air ducts in the figure, the assembled galvanized spiral air ducts are arranged and combined according to the number of galvanized spiral air ducts, and the size of galvanized spiral air ducts is checked. After the shaft position conforms to the drawing, it can be hoisted.

手動提升機可以由起重團隊進行協調。吊裝時注意平衡吊裝螺旋風管，防止側滑或傾覆。螺旋風管通過角鋼橫擔固定在支架和吊架上。安裝鍍鋅螺旋風管時，主管應盡量靠近梁底，支管盡量裝高。在交叉作業中，要配合水利工程和電力工程。鍍鋅螺旋風管安裝后，檢查鍍鋅螺旋風管的安裝高度是否符合設計要求，鍍鋅螺旋風管的高度和垂直度是否符合規范要求，支架是否歪斜，支架間距是否符合要求。

The manual hoist can be coordinated by the lifting team. When hoisting, pay attention to the balanced hoisting of spiral air duct to prevent side sliding or overturning. The spiral air duct is fixed on the support and hanger through the angle steel cross arm. When installing galvanized spiral air duct, the main pipe shall be as close to the beam bottom as possible, and the branch pipe shall be as high as possible. In cross operation, it is necessary to cooperate with water conservancy projects and electric power projects. After the installation of the galvanized spiral air duct, check whether the installation height of the galvanized spiral air duct meets the design requirements, whether the height and perpendicularity of the galvanized spiral air duct meet the specification requirements, whether the support is skewed, and whether the support spacing meets the requirements.
